2018 Evinrude E-TEC 60 HP E15HTSL H.O. Kicker Engine

MODEL	E15HTSL
MODEL YEAR	2018
SKU	E15HTSL
WEIGHT	250.0 lb
MANUFACTURER	Evinrude
COUNTRY OF MANUFACTURE	United States
HORSEPOWER	60hp
SHAFT LENGTH	25″ (Long)
STEERING	Tiller
STARTING	Electric and Rope
TRIM & TILT	High Speed Power Tilt
FUEL DELIVERY	E-TEC Direct Injection with stratified low RPM combustion mode
FUEL TANK	External
CYLINDER(S)	2
DISPLACEMENT	577 cc (35.2 cubic inches)
BORE AND STROKE	76 mm x 64 mm (2.992 x 2.5 inches)
FULL THROTTLE RPM RANGE	5,000-5,500 RPM
VALVES PER CYLINDER	2
FUEL TYPE	Unleaded Gasoline (87 octane)
OIL TYPE	Evinrude / Johnson XD-100 Oil
OIL CAPACITY	1.7 qt (1.6 L)
LUBRICATION	Multi-Point Targeted Oiling
ALTERNATOR	56 Amps Total / 15 Amps Net Dedicated
COOLING SYSTEM	Water Cooled
SALTWATER RATED	Yes
GEAR RATIO	2.15:1
GEAR SHIFT	Forward, Neutral, Reverse

1 X Outboard Motor

1 X Outboard Tiller Handle ( The size will be given depending on the type of outboard you buy )

1 X Fuel Tank ( The size will be given depending on the type of outboard you buy )

1 X Quick Connect Fuel Line tilt switch

1 x Teleflex SL3 Throttle control Top or side Mount  + Free Installation Universal Cables

1 X Outboard Warranty Card from manufacturer Valid 3-5 Years Depending on outboard type

1 X Standart Aluminum Propeller Depending on outboard Brands , type & Horse power.

1 X Trim limiter

3 X Gall Free Oil Depending on outboard Brands Yamalube, Honda Marine Oil, Mercury Premium Oil

1 X Stainless Outboard Anti-Theft

1 X Book Owner’s Manual Guide from manufacturer

1 X Ebook Installation Guide & And how to take care of the engine properly.

3 X Cable Protection System Length 800mm

Controls, Propeller, Battery, Fuel Tank, Line, and Stand are Included.

The motor has been inspected and is ready to mount and run. Freight Shipping is available from Southold, NY 11971, USA.

Please message us for a quote. For a freight quote, please email at info@orionoutboardmotorsunlimited.com and provide the following information:

• Country
• Zip code
• Commercial (with a loading dock) or residential delivery
• Liftgate service on truck required or not

NOTE – Please be sure to check all shipments for any potential damage during transit.

It is the sole responsibility of the receiving party to fully inspect the product at the time of delivery

for any potential damage.

We recommend removing any protective wrapping to fully inspect the product before the driver leaves.

If damage did occur during transit, all damage must be noted on the Bill of Lading in detail and SIGNED BY THE DRIVER.

A copy of the Bill of Lading will need to be emailed or mailed to us in order for a damage claim to be filed with the trucking company on our customers’ behalf. When possible, please photograph the damaged product on the truck and off the truck for evidence that will assist with a product damage claim.

The damaged product must be held in the customer’s possession up to 2 months.

The shipping company has the right to inspect and/or claim the product if a damage claim is filed and/or paid by them.
